ADC OPTION PROGRAMMING TABLE
Command
Code
Programming Command
Description
New Analog settings
1 2 3 4 5 6 7 8
Factory
Setting
56
ANALOG SCALING:
ADC offset values
0000
57
ANALOG SCALING:
ADC factorial values
1000
58
ANALOG SCALING:
Decimal point position
6
59
ANALOG SCALING:
Decimal point round off value
3
68
ANALOG SCALING:
Enable sign for analog scaled values
0
69
ANALOG SCALING:
Speech identifier for scaled values
245
"VOLTS"
70
Upper analog alarm limit
+4096
71
Lower analog alarm limit
-4096
72
Input integrate rate
4
73
Enable input to trigger alarm
0
74
Enable input to trigger alarm relay
0
75
Telephone number access
1
76
Select analog alarm message
00
77
Select alarm delay for analog alarm
0
78
Select single/differential ended input
0
79
Set analog high / low range
1
