Figure 8
Typical Control Subpanel Layout
1DPB
1DPT
1FU
GRD
1C
3C
2C
1M
2CR
1CR
1T
1DBLK
SYSMAC mini
omron
PLC
10L
A0547616
Refer to your Customer Information Packet on actual drawings for your specific dryer.
Page 22
WDMR and WDFR Series Dehumidifying Dryers
