3. Menu Operation DD35 Production Switcher
3 – 88 Operating Instructions – Rev. 16 / 10.2001
For details refer to section Introduction.
The Wiper Wash function offers a new option for wipe border design by permitting
color wash effects within the border.
Selecting Flat matte 1 serves to select a flat (plain) matte 1.
Selecting Wash serves to select a matte that is composed of a color wash between
matte 1 and matte 2.
If only the Wash button lights up, it is possible to change the color wash individually
with the Softness, Position, and Angle controls.
The Softness control permits adjusting the steepness, i.e. the width of the transi-
tion between the two colors. The Position control serves to shift the position of the
transition. With the Angle control, the transition angle can be rotated.
Select Flat Matte 1 or Flat Matte 2 if you wish to adjust the matte with the Hue,
Chroma, and Luminance controls.
Selecting Flat matte 2 serves to select a flat (plain) matte 2.
For details refer to section Introduction.
Menu Lock
Wiper Wash
Flat Matte 1
Wash
Flat Matte 2
Digits
