36
Specifications
Discrete Audio Inputs
Discrete Audio Inputs
The Kaleido-MX (1RU) supports one ABT/MADI audio input.
a. The Kaleido-X software does not distinguish between 1080PsF25 and 1080i50, between
1080PsF29.97 and 1080i59.94, between 720p29.97 and 720p30, and between
1080p29.97 and 1080p30. On the monitor wall and in XAdmin’s Status and Options
page, 1080PsF25 is reported as 1080i50, 1080PsF29.97 is reported as 1080i59.94, 720p30
as 720p29.97, and 1080p30 as 1080p29.97.
3G-SDI inputs
Signal SMPTE ST 424 (2.97, 2.97/1.001 Gbps)
Formats 1080p50
1080p59.94
Audio SMPTE ST 299
Return loss > 15 dB up to 1.5 GHz
> 10 dB up to 3 GHz
Alignment jitter (100 kHz) < 0.3 UI
Timing jitter (10 Hz) < 2 UI
Cable length 100 m (328 ft) (Belden 1694A)
45 m (148 ft) (Belden 1855A)
Graphic converted to HD-SDI from KXI-DVI-Bridge
a
a. A Dual Channel DVI to HD Bridge must be connected between the multiviewer and the PC
or laptop that provides the graphics to the multiviewer. To order this optional device
(Part No. KXI-DVI-BRIDGE), contact your Grass Valley sales representative.
Signal SMPTE ST 292-1 (1.485, 1.485/1.001 Gbps)
Format 1080p60
Cable length 100 m (328 ft) (Belden 1694A)
45 m (148 ft) (Belden 1855A)
ABT/MADI audio inputs
Signal SMPTE ST 259-C (270 Mbps), SMPTE ST 305
Format SDTI
Return Loss >15 dB up to 270 MHz
Alignment jitter (100 kHz) < 0.2UI
Timing jitter (10 Hz) < 1UI
Cable length 250 m (820 ft) (Belden 1694A)
150 m (492 ft) (Belden 1855A)
Connector DIN 1.0/2.3
