124 Kayak — User Manual
Section 3 — Control Panels
E-MEM thus permits storing and recalling individually prepared operating
statuses and timelines with different background, key sources, borders,
wipe pattern positioning, coloring etc.
The memo system is used for storing and recalling static settings (statuses,
snapshots) and interpolated timelines.
The snapshots and timelines are identified with numbers (Register 0 ... 99).
E-MEM can be operated in two ways:
• Operation via the buttons of the Effects panel section
• Operation via the menu (not implemented in current software release
version)
The number of keyframes in a timeline is only limited by the storage
capacity of the respective switcher computer and the number of mixing
levels and storable functions. The operator can edit a timeline in order to
produce more sophisticated effects.
Definition of Terms
The Store , Bank and Edit buttons have different functions in the various oper-
ations.
Table 6. Terms and Definitions
Term Definition
SNAPSHOT (SNAP) Switcher status or the status of a switcher part.
KEYFRAME (KF) Static switcher status within one timeline.
TIMELINE (TIML) Stored sequence of switcher statuses (keyframes).
DISSOLVE Dissolve between static switcher statuses.The analogue values are dissolved,
the switching functions are switched at the end of the dissolve procedure.
DISSOLVE TIME Time for dissolving between two static switcher statuses.
STORE Storing of a static switcher status.
RECALL Reproduction of a stored static switcher status.
EDITING (EDIT) Creation or the processing of a timeline outside real-time.
PLAY Play of a stored timeline.
TRAJECTORY “Trajectory” between keyframes.
REGISTER Memory location where a snapshot or a timeline can be stored. Registers are
identified with a number between 0 ... 99.
REGISTER MODE Input mode for the register number in the Effects subpanel, in which the
number is entered in one digit (0 ... 9) or in two digits (10 ... 99) followed by
functional selections such as Enter, Cut or Auto.
BANK MODE Input mode for the register number in the Effects subpanel. The bank number
0 ... 9 corresponds to the tens digit of the register number. When the units
digit of the register number is entered, the corresponding snapshot or time-
line is triggered immediately.
