blueplanet Operating and Installation Instructions 6400xi - 7600xi
4.4 Dimensions and weights
Figure 4.1: blueplanet dimensions
refer to table below for dimensions
Model
Height
(H)
Width
(W)
Depth
(D)
Weight
6400xi
44
1/8
in.
14 in.
8
7/8
in.
95 lbs
7600xi
44
1/8
in.
14 in.
8
7/8
in.
95 lbs
4.5 Inverter knockout dimensioning
Figure 5.1 (A): Inverter bottom knockout dimensions
Model
X
Y
6400xi 5
5
/
32
“
8
19
/
32
“
7600xi
5
5
/
32
“
8
19
/
32
“
Figure 5.1 (B): Inverter left view knockout dimensions
Model
X
Y
6400xi 5
5
/
32
“
3
25
/
32
“
7600xi
5
5
/
32
“
3
25
/
32
“
S e c t i o n 4 ·
U n i t D e s c r i p t i o n
H
W
D
X
Y
X
Y
