Creating New Frames
•
Defining the border: image format type .PNG
•
Define the overall border image size
<width>###</width>
<height>###</height>
Example of 6x4 @ 300 dpi:
•
<width>1800</width><height>1200</height>
•
Define top-left corner of alpha channel
<alpha x=“###” y=“###” width=“xxx” height=“xxx” rotation=“xx” />
This is where the image in the border starts, its top-left pixel location
•
Define the width & height of the alpha channel
<alpha x=“xxx” y=“xxx” width=“###” height=“###” rotation=“xx” />
This is how wide and tall you want your image in the border to be
•
Define rotation of the alpha channel
<alpha x=“xxx” y=“xxx” width=“xxx” height=“xxx” rotation=“###” /
Rotation measured in degrees
A value of 15 will rotate the image within the border 15 degrees
•
Aspect ratio per print size:
5x5
8x10
5x7
3.5x5
6x8
4x6
6x6
6x9
8x8
8x12
13x13
20x25
13x18
9x13
15x20
10x15
15x15
15x23
20x20
20x30
Image size in inches:
Image size in
centimeters
1.43
1.5
2
Multiply Short Side
by:
4:3
1.33
7:5
3:2
2:1
1
1.2 1.25 1.27
1.3
1.4
ASPECT RATIO
1:1
6:5
5:4
