Port name Type Width Description
config_dqs_io_ena Input 1 An input port that controls the
enable input on the DQS I/O
configurations. Receives the
clock enable signal for the DQS
I/O configuration block.
Refer to
Dynamic Reconfigura‐
tion for ALTDQ_DQS2 on
page 38
This port is supported in Arria
V, Cyclone V, and Stratix V
devices.
config_dqs_ena Input 1 An input port that controls the
enable input on the DQS logic.
Receives the clock enable signal
for the DQS configuration
block.
Refer to
Dynamic Reconfigura‐
tion for ALTDQ_DQS2 on
page 38
This port is supported in Arria
V, Cyclone V, and Stratix V
devices.
config_update Input 1 The ALTDQ_DQS2 dynamic
configuration interface consists
of this input port.
Receives the signal to load the
bits from the serial-to-parallel
shift registers to the configura‐
tion registers.
After scanning all the bits into
the desired scan chain blocks,
the bits can be copied at once
into the configuration register
by asserting the
config_update
signal for one clock cycle.
This port is supported in Arria
V, Cyclone V, and Stratix V
devices.
UG-01089
2014.12.17
ALTDQ_DQS2 Dynamic Configuration Ports 37
ALTDQ_DQS2 IP Core User Guide Altera Corporation
