8. To view the simulation results, on the Tools menu, select Run Simulation Tool and then click RTL
Simulation.
For a successful simulation, you may need to manually change alterapll.vo to alterapll.v in the auto-
generated top_run_msim_rtl_verilog.do file.
9. Before running the Fitter, ensure that the following settings are done in the Assignment Editor.
• I/O Standard
• Input Termination
• Output Termination
• DQ Group
• Location assignment for strobe pin—this helps the Fitter to fit the related DQ pins in the
appropriate l/O sub-banks. You can then back-annotate the locations if desired.
The following figure shows an example setting in the Assignment Editor and the Pin Planner results:
Figure 53: Assignment Editor Window
