3-38
Instruments and controls
may be considered normal.
. The warning light illuminates right
after the engine is started but goes out
immediately, remaining off.
. The warning light illuminates after
engine startup and goes off while the
vehicle is subsequently being driven.
. The warning light illuminates during
driving, but it goes out immediately and
remains off.
! Vehicle Dynamics Control OFF in-
dicator light
. It illuminates when the Vehicle Dy-
namics Control OFF switch is pressed.
. It also illuminates when the Vehicle
Dynamics Control system is deactivated.
NOTE
. The light may stay on for a while
after the engine has been started,
especially in cold weather. This does
not indicate the existence of a problem.
The light should go out as soon as the
engine has warmed up.
. The indicator light illuminates when
the engine has developed a problem
and the CHECK ENGINE warning light/
malfunction indicator lamp is on.
The Vehicle Dynamics Control system is
probably faulty under the following condi-
tion. Have your vehicle checked at a
SUBARU dealer as soon as possible.
. The light does not go out even after the
lapse of several minutes (the engine has
warmed up) after the engine has started.
&
Security indicator light
This indicator light shows the status of the
alarm system. It also indicates operation
of the immobilizer system.
! Alarm system
It blinks to show the driver the operational
status of the alarm system. For detailed
information, refer to the
“Alarm system”
section in chapter 2.
! Immobilizer system
This light blinks approximately 60 seconds
after the ignition switch is turned from
“ON” position to the “Acc” or “LOCK”
position or immediately after the key is
pulled out. Refer to the
“Door locks”
section in chapter 2.
If the indicator light does not flash, it may
indicate that immobilizer system may be
faulty. Contact your nearest SUBARU
dealer immediately.
In the event that an unauthorized key (for
example, an unauthorized duplicate) is
used, the security indicator light illumi-
nates.
&
SPORT mode indicator
light (4-speed AT mod-
els)
This light illuminates when the ignition
switch is turned to the
“ON” position and
goes out after the engine has started.
When the selector lever is moved to the
manual gate, the SPORT mode is se-
lected and the indicator light illuminates.
Refer to the
“Automatic transmission – 4-
speed ” section in chapter 7.
&
Shift-up indicator light
(MT models with SI-
DRIVE)
When the ignition switch is turned to the
“ON” position, the indicator light illumi-
nates for 3 seconds, and then turns off.
While selecting the Intelligent (I) mode of
SI-DRIVE, this indicator light illuminates
and informs the upshift timing to the driver
for fuel-efficient driving.
