& Center and side ventilators
! Center ventilators
Move the tab up and down or right and left
to adjust the flow direction.
! Side ventilators
1) Open
2) Close
Move the tab up and down or right and left
to adjust the flow direction.
To open the ventilator, turn the side grille
open/close wheel upward to the
“ ” posi-
tion.
To close it, turn the wheel downward to the
“ ” position.
Manual climate control sys-
tem (if equipped)
& Control panel
1) Temperature control dial
2) Fan speed control dial
3) Air flow control dial
4) Air conditioner button
5) Air inlet selection button
6) Rear window defogger button (Refer to
the
“Rear window defogger button” sec-
tion in chapter 3.)
Climate control
4-3
– CONTINUED –
4
