3. Unplug the coil pack and remove the four 7mm bolts that secure the coil pack to its
mounting bracket. Place the coil pack aside and remove the mounting bracket by removing
the three bolts. (Fig 5, Fig 6)
4. Remove the tensioner limiting bracket . Loosen but do not remove the four bolts securing
the water pump pulley. (Fig 7, Fig 8)
5. Using a 1/2” ratchet or breaker bar, rotate the belt tensioner clockwise then remove and
discard the drive belt. (Fig 9)
6. Remove the uppermost stud bolt on the tensioner. It will be used as a mounting point for
the supercharger bracket.(Fig 10)
COPYRIGHT 2000 PAXTON AUTOMOTIVE PAGE 4
ASSEMBLY MANUAL for the
1996-98 MUSTANG COBRA
P/N 4809609
FIG 5
FIG 9 FIG 10
FIG 8 FIG 7
FIG 6
