Introduction
MVME8100 / MVME8110 Installation and Use (6806800P25G) 22
1.2 Standard Compliances
The MVME8100 / MVME8110 is designed to be CE compliant and to meet the following
standard requirements.
I/O  One micro DB9 connector for console port on front panel
 One USB2.0 type A connector on front panel
 One front panel RJ45 connector with integrated LEDs for
10/100/1000 Ethernet channel
 PMC/XMC site 1 front I/O and rear PMC I/O
 PMC/XMC site two front I/O
 Four Serial ports to P2/RTM, two with micro DB9 connectors on RTM
panel and two on planar headers
 Two 10/100/1000BASE-T Ethernet channels to RJ45 connectors on
RTM panel
 Two 1000 BASE-BX Ethernet SERDES channels to backplane
 Two USB2.0 ports to RTM with USB type A connectors on RTM panel
 One SATA port to RTM with eSATA connector on RTM
 Two GPIOs to planar headers on RTM
Table 1-2 Features List of MVME8110 (continued)
Function Features
Table 1-3 Board Standard Compliances
Standard Description
UL 60950-1
EN 60950-1
IEC 60950-1
CAN/CSA C22.2 No 60950-1 Safety Requirements (legal)
CISPR 22
EN 55022
EN 55024
FCC Class A
VCCI Japan
AS/NZS CISPR 22 EMC requirements (legal) on system level (predefined Artesyn
Embedded Technologies system)
