Controls, LEDs, and Connectors
MVME8100 / MVME8110 Installation and Use (6806800P25G) 54
3.2.1 LEDS
3.2.1.1 Front Panel LEDs
Table 3-1 describes the LEDs on the front panel of the MVME8100 / MVME8110. Refer to Figure
3-1 for LED locations.
Table 3-1 Front Panel LEDs
Label Function Color Description
USER 1 User Defined Off By Default
Yellow User Software Controllable.
Red User Software Controllable.
FAIL Board Fail Off Normal operation after
successful firmware boot
Red One or more on-board power
rails have failed and the board
has shutdown to protect the
hardware. Normal during
power up, during hardware
reset (such as a front panel
reset). May be asserted by the
BDFAIL bit in the Tsi148 VSTAT
register
SPEED Link/Speed Off No link
Amber 10/100BASE-T operation
Green 1000 BASE-T operation
ACT Activity Off No activity
Blinking Green Activity proportional to
bandwidth utilization
