Controls, LEDs, and Connectors
MVME8100 / MVME8110 Installation and Use (6806800P25G) 62
3.2.2.2 On-board Connectors
The on-board customized SATA connector is compatible with the MVME8100 SATA kit.
Following are the onboard connectors:
 SATA connector
 PMC connector
 Asset JTAG connector
 COP connector
 XMC connector
SATA Connector:
The on-board customized SATA connector is compatible with the Artesyn Embedded
Technologies SATA kit MVME8100-HDMNTKIT4.
Table 3-8 Customized SATA Connector
Pin Name Signal Description Pin Name Signal Description
1 GND 21 GND
2 GND 22 SATA POWER ENABLE
3 NC 23 NC
4 SATA TX + 24 SATA DETECT
5 NC 25 NC
6 SATA TX - 26 GND
7 GND 27 NC
8 GND 28 GND
9 GND 29 GND
10 GND 30 GND
11 NC 31 +3.3V
12 SATA RX - 32 +5V
13 NC 33 +3.3V
14 SATA RX + 34 +5V
