Artesyn MVME8100/MVME8110 Installation and Use (September 2014) - Manual (Page 57)

Controls, LEDs, and Connectors
MVME8100 / MVME8110 Installation and Use (6806800P25G) 57
A7 DATA 6 B7 BGOUT1 C7 DATA 14 D7 NC Z7 NC
A8 DATA 7 B8 BGIN2 C8 DATA 15 D8 NC Z8 GND
A9 GND B9 BGOUT2 C9 GND D9 GAP Z9 NC
A10 SYSCLK B10 BGIN3 C10 SYSFAIL D10 GA0 Z10 GND
A11 GND B11 BGOUT3 C11 BERR D11 GA1 Z11 NC
A12 DS1 B12 BR0 C12 SYSRESET D12 +3.3V (not
used) Z12 GND
A13 DS0 B13 BR1 C13 LWORD D13 GA2 Z13 NC
A14 WRITE B14 BR2 C14 AM 5 D14 +3.3V (not
used) Z14 GND
A15 GND B15 BR3 C15 ADD 23 D15 GA3 Z15 NC
A16 DTACK B16 AM 0 C16 ADD 22 D16 +3.3V (not
used) Z16 GND
A17 GND B17 AM 1 C17 ADD 21 D17 GA4 Z17 NC
A18 AS B18 AM 2 C18 ADD 20 D18 +3.3V (not
used) Z18 GND
A19 GND B19 AM 3 C19 ADD 19 D19 NC Z19 NC
A20 IACK B20 GND C20 ADD 18 D20 +3.3V (not
used) Z20 GND
A21 IACKIN B21 NC C21 ADD 17 D21 NC Z21 NC
A22 IACKOUT B22 NC C22 ADD 16 D22 +3.3V (not
used) Z22 GND
A23 AM 4 B23 GND C23 ADD 15 D23 NC Z23 NC
A24 ADD 7 B24 IRQ7 C24 ADD 14 D24 +3.3V (not
used) Z24 GND
A25 ADD 6 B25 IRQ6 C25 ADD 13 D25 NC Z25 NC
Table 3-5 P1 Connectors (continued)
P1 Connector (1st
Row) P1 Connector (2nd
Row) P1 Connector (3rd
Row) P1 Connector (4th
Row)
P1 Connector (5th
Row)
Pin
Name Signal
Description Pin
Name Signal
Description Pin
Name Signal
Description Pin
Name Signal
Description Pin
Name Signal
Description
