SLM-5650A Satellite Modem Revision 8
Front Panel Operation MN-SLM5650A
5–6
5.2.1 SELECT (Main) Menu Matrix
Menu Branch Para Nested Menu Sect Selectable Submenus
Configure 5.2.2 Tx 0 Mod, DataRate, Overhead, Frequency,
Power, Clocking, Misc, Spreading
Rx 5.2.3.2
Demod, DataRate, Overhead, Frequency,
Acquisition, Buffer, Misc, CnC, Spreading
Mode 5.2.3.3 Mode, FreqBand, Interface
AUPC 5.2.3.4 Local, Remote, Async, Logging
TRANSEC 5.2.3.5 State, Module IP Address, Gateway
AntHndOvr 5.2.3.6 Mode, State, PwrOffset, Delay
Ref 5.2.3.7 Internal, Ext-1 MHz, Ext-5 MHz, Ext-10 Mhz
Mask 5.2.3.8 TxData, RxData, Eb/No Threshold, DemodFaults
Reset 5.2.3.9
Remote 0
Mode, SerialConfig, EthernetConfig (w/Option
Cards)
Monitor 0 Alarms 5.2.4.1 Transmit, Receive, Unit
Event-Log 5.2.4.2 View, Clear-All, ModemParameters
Rx-Params 0
CnC 5.2.4.4
Stats 5.2.4.5 View, Clear-All, Config
Gigabit IF Statistics 0
Test 5.2.5 Carrier 5.2.5.1 Normal, Tx-CW, Tx-1,0
Loopback 5.2.5.2 Normal, IF, I/O1
Bert 5.2.5.3 Tx, Pattern, ErrIns, Reset, Rx
LampTest 5.2.5.4
Save/Load 5.2.6 Save/Load Loc, Action
Utility 5.2.7 RT-CLK 5.2.7.1
RefAdjust 5.2.7.2
ID 5.2.7.3
Display 5.2.7.4
Temp 5.2.7.5
AGC 5.2.7.6
Alarm 0
PwrCal 5.2.7.8
Firmware 5.2.7.9 Information, Select
FAST 0 Configuration, View Options
