Daktronics Fuelight FL-3000 and FL-4500 Series 36 and 48 Petroleum Price Display and Cash/Credit Display - Manual (Page 49)

Replacement Parts 43
Section 10: Replacement Parts
Important Notes:
• Disconnect power before any repair or maintenance is done on the display.
• Only qualified service personnel should make any access to internal
display electronics.
• Disconnect power when the display is not in use.
10.1 About Replacement Parts
Most components within the display carry a label
that lists the part number. A typical label is shown in
Figure 49 with the part number in bold. Use the part
number on the label to easily identify replacement
parts.
10.2 Replacement Part Numbers
Refer to Section 11 for instructions on obtaining parts
from Daktronics.
0P-1127-0024
SN: 2465
02/19/12 Rev. 1
Figure 49: Typical Parts Label
Part Description Part Number
FLR3-100 Kit 0A-1611-0601
FLR3-1500 Fixed Radio Kit 0A-1611-0603
FLD3-2000 G3 Wired Kit 0A-1611-0604
Driver Assembly; Gas Price III 0A-1611-0400
Power Supply A-2743
Power Supply Harness 36" W-2642
2 Pin Harness - 48" W- 2641
9 Pin Sealed Harness - 120" W-2644
5 Pin Harness - 48" W-2457
Line-to-Line Cable - 15' 0A-1611-0507
Line-to-Line Cable - 50' 0A-1611-0511
Line-to-Line Cable - 100' 0A-1611-0509
Line-to-Line Cable - 200' 0A-1611-0510
FL3 Breakout Board 0A-1735-0400
36" Red Horizontal Segment 0A-1735-5121
36" Red Vertical Segment 0A-1735-5122
16" Red Digit (to represent 9 of 9/10) 0A-1611-5111
Red Decimal 0A-1611-5132
36" Amber Horizontal Segment 0A-1735-5221
36" Amber Vertical Segment 0A-1735-5222
16" Amber Digit (to represent 9 of 9/10) 0A-1611-5211
Amber Decimal
0A-1611-5232
36" Green Horizontal Segment 0A-1735-5321
36" Green Vertical Segment 0A-1735-5322
16" Green Digit (to represent 9 of 9/10) 0A-1611-5311
Green Decimal 0A-1611-5332
48" Red Horizontal Segment 0A-1735-5123
48" Red Vertical Segment 0A-1735-5124
18" Red Digit (to represent 9 of 9/10) 0A-1611-5113
48" Amber Horizontal Segment 0A-1735-5223
48" Amber Vertical Segment 0A-1735-5224
18" Amber Digit (to represent 9 of 9/10) 0A-1611-5213
48" Green Horizontal Segment
0A-1735-5323
48" Green Vertical Segment 0A-1735-5324
18" Green Digit (to represent 9 of 9/10) 0A-1611-5313
