Hardware Installation
Pins
1
3
5
7
9
1 1
1 3
1 5
1 7
1 9
2 1
2 3
2 5
Function
5 V
5 V
5 V
N. C.
N. C.
N. C.
DRVDE0
GND
GND
GND
GND
GND
GND
Pins
2
4
6
8
1 0
1 2
1 4
1 6
1 8
2 0
2 2
2 4
2 6
Function
INDEX#
DR0#
DSKCH#
N. C.
MTR0#
DIR#
STEP#
WDATA#
WGATE#
TRK0#
WRPRO#
RDATA#
HDSEL#
FPC Type FDD Connector
