![background image](/files/781841/content/doc032.png)
32
DR
®
DUAL-ACTION ELECTRIC LOG SPLITTER
Parts List – MOTOR AND PUMP ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part#
Description
1
27610
Sheathing, Abrasion Resistant, 15.5"
2
11214
Tie, Cable, 7 1/2"L
3
25616
Hyd Adapter, Jcm08-Obm08-90
4
25346
Hyd Adapter, Jcm06-Obm08
5
25348
Hyd Adapter, Jcm06-Obm08-90
6
25333
Hose Assembly, Hyd, Tank-Pump, 12.5"
7 29364 Hose,
Hyd,
15"
8
11238
Washer, Flat, 1/4", USS
9
11076
Nut, Nylon Lock, 5/16-18
10
29512
Filter, Hyd, In tank
Ref# Part#
Description
11
11158
Bolt, HCS, 5/16-18 X 1"
12
29511
O-ring, 28.5mm X 2.4mm
13 29358
Pump,
Hyd,
6L/Min
14
29366
Motor, 1.8kw, 120V, 60Hz
15
11243
Washer, Lock, Split, 5/16"
16
27629
Bolt, SHCS, M8-1.25 X 20
17 27609
Label,
Motor,
Electric
18
29503
O-ring, 22mm X 2.4mm
Items Not shown in illustration
29381 Pump
Assembly,
Motor
