Chapter 2: Setting Up The DR DUAL-ACTION ELECTRIC LOG SPLITTER
It may be helpful to familiarize yourself with the controls and features of your DR DUAL-ACTION ELECTRIC LOG SPLITTER as
shown in Figure 1 before beginning these procedures. If you have any questions at all, please feel free to contact us at
www.DRpower.com.
DR DUAL-ACTION ELECTRIC LOG SPLITTER Controls and Features
Splitting Wedge
Hydraulic
Fluid Pump
Assembly
Electric Motor
On-Off Switch
Electric Motor
Electrical Cord
Log Tray
Dipstick/Hydraulic
Fluid Fill
Reset
Button
Hydraulic
Fluid Tank
