52
Insert the fitting bracket into the left
and right-hand sides of the ventilation
grille on the charger’s front panel, and
do the same on the rear panel
Mark the location of the holes on the
mounting surface (see diagram for
measurements)
Drill holes
Select the most suitable screws for fas-
tening the charger according to the na-
ture of the mounting surface (diameter
5 mm)
Fasten charger to the mounting sur-
face using fitting brackets, each with
two screws
370 mm
42 mm
1
2
3
4
5
