60
External power supply
Starting the exter-
nal power supply
IMPORTANT! Start external power supply manually if:
-
there is no battery connected to the vehicle
- the battery voltage on the connected battery is < 1.0 V
Starting the exter-
nal power supply
manually
1
Select FSV/SPLY mode by pressing the info button
Connect (+) charging terminal to positive pole on battery
Connect (-) charging terminal to negative pole on the battery, or to vehicle body (e.g.
engine block) in the case of vehicle electrical systems
Charger detects that the battery is connected, carries out a self test and starts ex-
ternal power supply.
Self test
- the maximum voltage command value set in the
USER menu is shown in the top half of the dis-
play.
- the current parameters are shown in the bottom
half of the display.
By pressing the info button, the parameters are displayed in the following sequence:
-
actual charging current
- actual battery voltage
- amount of charge (Ah) fed in so far
- energy (Wh) fed in so far
- length of time charging so far
2
3
4
CAUTION! Risk of serious damage as a result of incorrectly connected charging
terminals. The reverse polarity protection facility is inoperative if the external pow-
er supply is started manually.
Connect charging terminals to correct poles and ensure proper electrical connec-
tion to vehicle terminals.
