Commercial and Retail Parts Hydraulic Related Parts
Page 5 PT-1950D Atlas™ Recommended Spare Parts Manual · March 2013
Hydraulic Related Parts
Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F option only = optional pulse out interface board
Pumps = all pumping units
ASC Distributor
Part Description Part Number Where Used Also Used Critical 100 100 500
Filter, High Capacity R20039 All Gasboy and
Legacy Medium 10 20 50
Meter Check Valve N23619-G2 All Gasboy and
Legacy Medium 4 8 12
Meter, CFT T20150-G5 Electronic - Medium 1 2 3
Meter, CFT Gallons T20150-G6 Mechanical - Medium 1 2 3
Meter, CFT Liters T20150-G7 Mechanical - Medium 1 2 3
Meter, CFT, Master Seal Kit K96618 All Legacy Retail
Electronic Medium 1 2 3
Meter, Quad Shaft Seal Kit K35222 All Gasboy and
Legacy Medium 1 2 3
Strainer High Capacity R19457 All Legacy Medium 2 3 5
Two Stage Valve (110 VAC) 067034 9200 Series - Medium 2 2 4
Two Stage Valve (220 VAC) 067036 9200 Series - Medium 2 2 4
Valve and Manifold 120 V M04607B001 All 120 V - Medium 1 2 3
Valve and Manifold 220 V M04607B002 All 220 V - Medium 1 2 3
Valve Coil Kit 120 V M04607K012 All 120 V - Medium 2 3 4
Valve Coil Kit 220 V M04607K013 All 220 V - Medium 2 3 4
Valve Diaphragm Kit M04607K010 All - Medium 2 3 4
Programmable Pump Preset (PPP) Options
Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F option only = optional pulse out interface board
Pumps = all pumping units
ASC Distributor
Part Description Part Number Where Used Also Used Critical 100 100 500
Programmable Preset Assembly R20267-G5 8800 Series with
Option Legacy Retail
Electronic Medium 2 4 7
Programmable Preset Board T17331-G2 8800 Series with
Option Legacy Retail
Electronic Medium 1 2 4
Programmable Preset Display PCA T17328-G1 8800 Series with
Option Legacy Retail
Electronic Medium 1 2 4
Programmable Preset Overlay T17885-XX 8800 Series with
Option Legacy Retail
Electronic Medium 3 5 8
