MDE-4628 AST Adapter Kit Installation Instructions • December 2006
Page 5
AST Adapter Kit Installation Instructions for 9x20 Upgrade
AST Adapter Kit Installation Instructions for 9x20 Upgrade
To install the AST Adapter Kit for 9x20 models, proceed as follows:
1
Remove the existing pumping unit.
2
Install the adapter on one side of the pumping unit using two adapter brackets and two M8
flange nuts, as shown in the figure below.
Figure 1:
Adapter Bracket
Assembly (1)
M8 Flange Nut (2)
AST Adapter Kit Installation
The installation of the AST Adapter Kit is complete.
