MDE-4337G Gilbarco® CRIND® PC Interface for Site Controller III with Windows® · February 2011
Page 7
Gilbarco CRIND Keyboard Layout System Parameter
Setup for PC-based Application using SC III
The position numbers of the keys on the FlexPay EPP keypad are as follows:
Note: The numbers 1-24 represent the position in the SYS_PAR string.
The FlexPay EPP keypad position numbers are programmed using a grid system consisting of
rows and columns. The row (R) and column (C) combination programmed in the FlexPay EPP
keypad are mapped to the position numbers in the SYS_PAR string. For example, R3C4 is
equal to the position number 14 in the SYS_PAR string or “A” in the string as follows:
123uu456uu789AuC0EuuYNXH.
The default factory key mapping of the FlexPay EPP CRIND keypad is as follows:
The string entered in to the SYS_PAR parameter to obtain the CRIND keypad function
arrangement shown above is 123uu456uu789uuC0EuuYNXH.
Note: To include payment soft keys on the CRIND device’s graphic display, replace the unused
keys (u) with the required soft keys (B, b, D, d, $, c).
C1
C2
C3
C4
C5
C6
R1
1
2
3
4
5
21
R2
6
7
8
9
10
22
R3
11
12
13
14
15
23
R4
16
17
18
19
20
24
C1
C2
C3
C6
R1
R1C1 or #1
R1C2 or #2
R1C3 or #3
R1C6 or #21
R 2 R2C1 or #6
R2C2 or #7
R2C3 or #8
R2C6 or #22
R 3 R3C1 or #11
R3C2 or #12
R3C3 or #13
R3C6 or #23
R 4 R4C1 or #16
R4C2 or #17
R4C3 or #18
R4C6 or #24
If the default SYS_PAR string does not produce the expected results when the key is
pressed, refer to the
“Mapping of FlexPay EPP Keypad Using the CRIND Diagnostic Card”
