Item Description Part Number
1 Gasket-Inlet/Outlet 027055
2 Flange-Meter Inlet 015496
3 Flange Plate-Meter Inlet 015495
4 Piping-Pump Outlet 015497
5 O-Ring 023091
Parts List 582/583 Piping
Page 40 MDE-4766 Series 580 Installation/Operation/Parts Manual · April 2009
023070 Pipe Assembly
Item Description Part Number
1 Gasket-Inlet/Outlet 027055
2 Flange, 1-inch 003650
3 Pipe TBE, 1 x 3 044525
4 Elbow, 1-inch x 90 024895
5 Pipe TOE, 1 x 4 045235
6 Adapter, 1-inch Cimtek 400
Filter 003087
7 Coupling Nipple, 4-3/4 015498
8 Elbow, Dresser 1 x 90 024910
9 Pipe TOE, 1 x 2-1/2 045218
10 Dresser Elbow Seal, 1-inch 054207
023079 Pipe W/Filter Assembly
