5-7 powermax 600 Service Manual
PARTS LIST - 208-240/480V
RECOMMENDED SPARE PARTS - POWERMAX600- 208-240/480V
Part Number Description Page
Reference
001668 ........................... Front end panel .................................................................... 5-2
001669 ........................... Rear end panel .................................................................... 5-2
008965 ........................... Knob ..................................................................................... 5-2
010287 ........................... Warning label ....................................................................... 5-2
110271 ........................... Operation lable ..................................................................... 5-2
129594 ........................... Power supply cover .............................................................. 5-2
041654 ........................... Control PCB assembly ......................................................... 5-3
108090 ........................... Terminal block ...................................................................... 5-3
123375 ........................... Work Cable with clamp, 4.6 m/15 ft ..................................... 5-3
129533 ........................... Solenoid valve ...................................................................... 5-3
129534 ........................... Quick disconnect assembly ................................................. 5-3
003193 ........................... Circuit breaker, 480 V .......................................................... 5-4
003202 ........................... Circuit breaker, 208-230V .................................................... 5-4
023519 ........................... Power cable, 480V ............................................................... 5-4
129530 ........................... Power cable, 208-230V ........................................................ 5-4
005112 ........................... Pressure Switch ................................................................... 5-5
011083 ........................... Filter regulator subassembly ................................................ 5-5
011086 ........................... Air filter element ................................................................... 5-5
011087 ........................... O-ring, Air filter element ....................................................... 5-5
014232 ........................... Inductor, output choke .80MH 40A ...................................... 5-5
014251 ........................... Power transformer, 208-240V .............................................. 5-5
022027 ........................... Pressure gauge .................................................................... 5-5
027654 ........................... Fan assembly ....................................................................... 5-5
014252 ........................... Power transformer, 480V ..................................................... 5-5
109179 ........................... Capacitor, 1800/1900UF 450V, 480V .................................. 5-5
109187 ........................... Capacitor, 1800/1900UF 250V, 208-230V ........................... 5-5
129366 ........................... Fan subassembly, 480V ...................................................... 5-5
005222 ........................... Temp switch ......................................................................... 5-6
009849 ........................... Resistor, 20 OHM ................................................................ 5-6
041650 ........................... Power PCB, 208-240V ......................................................... 5-6
041652 ........................... Power PCB, 480V ................................................................ 5-6
109079 ........................... IGBT module, 480V ............................................................. 5-6
109080 ........................... IGBT, pilot arc ...................................................................... 5-6
109088 ........................... Output diode ........................................................................ 5-6
109174 ........................... Input diode bridge, 208-240V ............................................... 5-6
109175 ........................... Input diode bridge, 480V ...................................................... 5-6
109183 ........................... IGBT module, 208-240V ...................................................... 5-6
027662 ........................... Thermal grease, 5 oz. DC-340 ............................................. 5-6
008903 ........................... Thermal pad ......................................................................... 5-6
