18

5.2.5 Confirm

Various

Settings

1 Confirm Layout Style Settings

Confirm CH1 to CH4 screens. If the screen is different from the setting,

please refer to

5.2.4 Settings (Image Input Settings)

to reset image input.

Press the

button on the remote control and check if the 9 layout

recording styles are consistent with the settings. Blue indicates that a

style is currently applied. Press

again to exit.

Press the

button on the remote control and check if the 9 layout

styles are consistent with the settings. Blue indicates that a style is

currently applied. Press

again to exit.

2 Confirm Capture Screenshot Function

Use the remote control to test the Capture Screenshot function. If it fails,

please refer to

5.2.4 Settings (Format Hard Drive)

to check whether the

hard drive is properly installed.
Press

on the remote control to take a screenshot.

3 Confirm Recording Function

Use the remote control to test the recording function. If recording fails, refer

to

5.2.4 Settings (Format Hard Drive)

to check whether the hard drive is

properly installed.
Press ● on the remote control to access the recording screen. Press ●

again to begin recording. Recording begins following the countdown.

Press

■ to stop recording.

4 Confirm Playback Function

Use the playback function to confirm screenshot and recording results.
Press

on the remote control to access the OSD menu.

Select [Playback] ->[Local Storage]
[Photo] ->Select folder by date ->Select picture
Press

to exit picture browser.

[Video] ->Select folder by date ->Select and playback video.
Check whether the record screen layout and audio are normal and

whether video and audio are synchronized. If the video and audio are not

synchronized, go to the Recording Setting in System Configuration,

adjust audio lag, and repeat the recording and playback actions until the

playback is synchronized.

Press

to exit video playback.

Press

to exit screen.

Installation is completed once the above functions operate normally.
