48
 Timed: Set to automatically add a keynote at a set time while
recording
[Remark 1] When using PPT index, a keynote is automatically added each time a
page is changed
[Remark 2] Keynotes can be renamed or deleted in the Configuration. Refer to
7.2.10 Edit Lecture Keynote for detailed instructions
8.2.4 Network Camera Control
 Select Camera: Select Channels 1 to 4 to switch between camera channels
 Rotate Camera: Click the keypad on the right to rotate the camera lens.
Click [Home] to return the lens to the center position
 Rapidly Change Camera Angle: Click [Presets 0 to 9] to rotate the camera
lens to the set position
 : Drag the scroller to enlarge (W) or shrink (T) the screen
[Remark 1] The default position can be changed in the Configuration. Refer to
7.2.4.3 Network Camera Information for detailed instructions
8.2.5 Other Recording Settings
 Change Local Recording Output Resolution: The local recording output
resolution can be changed in [Storage Encode Profile]
 Change Streaming Media Output Resolution: The streaming media
output resolution can be changed in [Streaming Encoding Profile]
 Streaming Mode-RTP: When selecting [RTP Multicast] in [Streaming
Mode], depending on IP address and connection ports, recordings can be
synchronously viewed through VLC software or local CaptureVision
Station systems
 Streaming Mode-Online Director: When selecting [Network Streaming]
in [Streaming Mode], the connection address can be directly entered into
the URL field to stream video while recording
8.2.6 Webpage Language
Click [Language] at the bottom right of either the Network Configuration or
Director screen to switch the operating language at any time. Currently, the
system supports [Traditional Chinese/Simplified Chinese/English].
