eZ-Analyst 878193 Menus 3-11
Export Menu
Export Menu > Time History Data …
This window is used to export recorded files as Text (ASCII) files.
Source Information Panel
This panel, located at the top of the window, contains basic information about the source file
(see figure).
Export Window
Destination Information Panel
Note: For 600 Series, WaveBooks, and ZonicBook/618E analyzers the file format is Text (ASCII).
1. In the Filename data entry box, type the directory path and file name for the recorded
file, or use the <Browse> button to locate the desired file. The correct file extension will
be appended to the file name later, when the <OK> button is clicked.
2. Specify the First (Starting) and Last (Ending) records (blocks) that you want saved. In
the first figure above, “1” is specified for the Starting Block and “88” is specified for the
Ending Block.
3. Specify the channels of interest. Click to place a checkmark in the channel box for each of
the channels you want to export. The selected channels will be adjusted to continuous
channels starting with channel 1, but all the properties [including labels] will retain the old
definition. For example, selected channels 1,3,5,6,8,16 would be adjusted to channels
1,2,3,4,5,6 in the exported file.
4. If desired, change the gain and/or offset values on a per-channel basis.
5. Click the <OK> button.
