eZ-Analyst 978891 Software Installation, WaveBooks 1-1
Software Installation 1
WaveBooks …… 1-1
ZonicBook/618E …… 1-3
IOtech 600 Series
…… 1-5
WaveBooks
System Requirements
Certain WBK options are not supported by eZ-Analyst. If you are using
WBK options with WaveBook and intend to use eZ-Analyst, refer to the
WBK support table on page 1-2.
Before setting up the hardware or installing the software, verify that you have the following
items.
WaveBook data acquisition system
Power supply with cord
For WaveBook/516E: Ethernet patch cable
Dynamic Signal Analysis CD
License Key for eZ-Analyst
In addition, verify that your computer meets the following minimum requirements.
Monitor: SVGA, 1024 x 768 resolution
For WaveBook/516E: 10/100BaseT Ethernet port
Windows 2000 SP4 and Windows XP users:
Intel
™ Pentium, 1 GHz or equivalent;
512 MB memory; 10 GB disk space
Windows Vista users:
PC must be Windows Vista Premium Ready
Optional, but recommended:
EPP (Enhanced Parallel Port), or
ECP (Extended Capabilities Port)
Software Installation for WaveBooks
Remove any previous-installed versions of WaveBook software before installing a
new version.
1. Start Windows.
2. Close all running applications.
3. Insert the Dynamic Signal Analysis CD into your CD-ROM drive and wait for the CD to
auto-run.
If the CD does not start on its own :
(a) click the desktop’s <Start> button
(b) choose the Run command
(c) select the CD-ROM drive, then select the setup.exe file.
(d) click <OK>.
An Opening Screen will appear.
