Measurement Computing eZ-Analyst rev.14.1 - Manual (Page 86)

4-50 Edit Menu 978791 eZ-Analyst
You can enter the zero based column number into the entry box, or click on the column header of the desired
channel. At this point you can press the Back button to change your selection, or press Finish to start
importing data.
The next figure shows Step 2 of 2 for the Fixed width data format. For the fixed width format, you must
indicate how many characters wide the channel column is; then you select the channel (column number) to
import.
Text Import Wizard – Step 2 of 2 for “Fixed Width” Format
After completing these two actions, press the Finish button.
Data Import in Progress
Importing ASCII data can take several seconds. While the data is being imported a progress bar is displayed
as indicated in the above figure.
When all of the data has been imported, the dialog display changes. See following figure.
Fixed column
width
Import column
number
