51
ENGLISH
USB
USB port (A-type)
Playable MP3
Supported standard . . . . . . . . . . . . . . . . . . .MPEG-1/2 Audio Layer-3
File name extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . “.mp3”
Sampling frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32, 44.1, 48 kHz
Bit rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8–320 kbps
Maximum number of folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .255
Maximum number of files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .999
Playable WMA
Supported standard . . . . . . . . . . . .Windows Media Audio Standard
(DRM not compatible)
File name extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . “.wma”
Recording format (MP3)
Recording bit rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128 kbps
Sampling frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44.1 kHz
USB port (B-type) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .×1
Computer system requirements
Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . USB 2.0 full-speed
(12 Mbps, equivalent to USB 1.1)
Driver
Windows . . . . . . . . . . . . . . . . . . . . . . . . . WDM (Windows standard driver)
Mac OS X . . . . . . . . . . . . . . . . . . .Core Audio (Macintosh standard driver)
Verified operating systems
Windows . . . . . . . . . . . . . . . . . . Windows XP, Windows Vista, Windows 7
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mac OS X 10.5.8
< Operation with standard computers that meet the above requirements
has been confirmed, but operation with every computer that meets
the above requirements is not guaranteed. Even with computers that
meet the same requirement, each computer will have different process-
ing capabilities according to their design specifications and operating
environments.
General
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AC 230 V, 50 Hz (Europe/UK Model)
AC 120 V/230 V, 50-60 Hz (General Export Model)
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 W
Dimensions (W × H × D) . .435 × 145 × 288 mm (including protrusions)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.6 kg (12 1/3 lb)
Operating temperature range . . . . . . . . . . . . . . . . . . . . . . . . . . +5˚C to +35˚C
Operating humidity range . . . . . . . . . . . . . . .5% to 85% (no condensation)
Storage temperature range . . . . . . . . . . . . . . . . . . . . . . . . . . . .−20˚C to +55˚C
Included accessories
Remote control (RC-1283) ×1
Batteries (AAA) for remote control unit ×2
Stereo RCA pin cable ×2
Owner’s manual (this document) ×1
Warranty card ×1
Specifications
CD recorder
Pickup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-beam, semiconductor laser
Recording media . . . . . . . . . . . . . . . . . . . . . . . . .CD-R/CD-RW discs for music
Recording sampling frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44.1 kHz
Frequency response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Hz–20 kHz
(during playback: ±1.5 dB,
during recording/playback: ±2.0 dB)
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90 dB or higher (during playback)
90 dB or higher (during digital recording/playback)
80 dB or higher (during analog recording/playback)
Dynamic range . . . . . . . . . . . . . . . . . . . . . .86 dB or higher (during playback)
86 dB or higher (during digital recording/playback)
78 dB or higher (during analog recording/playback)
Total harmonic distortion . . . . . . . . . . . . 0.05% or lower (during playback)
0.05% or lower (during recording/playback)
Analog output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.0 V (RCA)
Cassette deck
Track format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-track, 2-channel stereo
Head structure. . . . . . . . . . . . . . . . recording/playback head ×1 (reversible)
Erasure head ×1
Tape type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-60 cassette tape
Tape speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.76 cm/sec
Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .DC servomotor ×1
Pitch control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . about ±10% (playback only)
Wow and flutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.25% (W.RMS)
Frequency response (total) . . . . . . . . . . . . . . . chrome: 50–12,000 Hz ±3 dB
normal: 50–12,000 Hz ±3 dB
S/N ratio (total) . . . . . . . . . . . . . . . 59 dB (Dolby NR off, 3% THD level WTD)
69 dB (Dolby NR on, 5 kHz or higher)
Winding time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . about 150 sec (C-60 tape)
Line input (RCA) . . . . . . . . . . . . .0.46 V (input impedance 20 kΩ or higher)
Line output (RCA). . . . . . . . . . . . .0.46 V (load impedance 50 kΩ or higher)
Headphone output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 mW/32 Ω
PHONO input
Input sensitivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.5 mV, 47 kΩ
Digital audio input
Input sampling frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32, 44.1, 48 kHz
< Specifications and appearance are subject to change without
notice in order to improve the product.
< Illustrations in this manual might differ in some aspects from the
actual model.
