15-42
To do…
Use the command…
Remarks
Configure an IPv4 address for the
tunnel interface
ip address ip-address { mask |
mask-length }
Required
By default, no IPv4 address is
configured for a tunnel interface.
Set the tunnel mode to GRE over
IPv6.
tunnel-protocol gre ipv6
Required
By default, the tunnel is a GRE
over IPv4 tunnel
Note that you need to configure
the same tunnel mode on both
ends of a tunnel. Otherwise,
packet delivery will fail.
Configure the source address or
interface for the tunnel interface
source { ipv6-address |
interface-type interface-number }
Required
By default, no source address or
interface is configured for a tunnel
interface.
Configure the destination address
for the tunnel interface
destination ipv6-address
Required
By default, no destination address
is configured for a tunnel interface.
Configure a route through the
tunnel
Refer to the Layer 3 - IP Routing
Configuration Guide.
Optional
Each end of the tunnel must have
a route (static or dynamic) through
the tunnel to the other end.
Note that:
z
If you delete a tunnel interface, the functions configured on this tunnel interface will be removed as
well.
z
The source address and destination address of a tunnel uniquely identify a path. They must be
configured at both ends of the tunnel and the source address at one end must be the destination
address at the other end and vice versa.
z
Tunnel interfaces using the same encapsulation protocol must have different source addresses
and destination addresses.
z
If you configure a source interface for a tunnel interface, the tunnel interface takes the primary IP
address of the source interface as its source address.
z
When configuring a route through the tunnel, you can configure a static route, using the address of
the network segment the original packet is destined for as its destination address and the address
of the peer tunnel interface as its next hop. Or, you can enable a dynamic routing protocol on both
the tunnel interface and the router interface connecting the private network, so that the dynamic
routing protocol can establish a routing entry that allows the tunnel to forward packets through the
