Table of alarms – Grass Valley 8925DMB-B User Manual
Page 47
8925DMB-B and -U — Instruction Manual
47
Service
Table of Alarms
below describes the different type of alarms reported to upper level
devices such as the 8900NET module and SNMP reporting applications.
Note
Operation Indicator LEDs on page 19
ations and Functional Elements on page 24
for the status and the color of the
LED.
Table 4. List of Alarms for 8925DMB Module
Alarm
Type
Web Page Description
FAULT
LED
VID IN
ERR LED
Comments
Status
Reported
to 8900Net
& SNMP
Fault
Firmware failure
On
Off
Firmware configuration failure
Yes
Fault
Firmware DCM Not Locked
On
Off
Firmware internal system clock failure
Yes
Fault
Bad firmware image
On
Off
A wrong firmware Image has been downloaded
Yes
Fault
Wrong rear module (incompatible with
8925DMB)
On
Off
Yes
Fault
Fiber module failed, replace
On
Off
Yes
Fault
Power supply failure
On
Off
Yes
Warning
Coax video input signal not detected
Flashing
Off
Video Input Coax is selected
Yes
Warning
Coax video input is invalid or the wrong format
Flashing
On
Video Input Coax is selected
Yes
Warning
Fiber 1 video input signal not detected
Flashing
Off
Video Input Fiber 1 is selected
Yes
Warning
Fiber 1 video input is invalid or wrong format
Flashing
On
Video Input Fiber 1 is selected
Yes
Warning
Fiber 1 video input not supported by hardware
Flashing
Off
Video Input Fiber 1 is selected
Yes
Warning
Fiber 2 video input signal not detected
Flashing
Off
Video Input Fiber 2 is selected
Yes
Warning
Fiber 2 video input is invalid or wrong format
Flashing
On
Video Input Fiber 2 is selected
Yes
Warning
Fiber 2 video input not supported by hardware
Flashing
Off
Video Input Fiber 2 is selected
Yes
Warning
Hardware configuration does not support
selected fiber video output
Off
Off
Fiber module is an RX/TX and user chose to
enable Fiber TX1 or fiber is Dual RX
Yes
Warning
Coax Video Standard does not match with
selection
Flashing
On
Current Coax Video input is not in the Input
Standard Selection table
Yes
Warning
Fiber 1 Video Standard does not match with
selection
Flashing
On
Current Fiber 1 Video input is not in the Input
Standard Selection table
Yes
Warning
Fiber 2 Video Standard does not match with
selection
Flashing
On
Current Fiber 2 Video input is not in the Input
Standard Selection table
Yes
Information
Fiber module is not installed
Off
Off
Fiber Input and Output are not selected
No
Information
Coax video input signal not detected
Off
Off
Video coax input not present, but not selected
No
Information
Fiber 1 video input signal not detected
Off
Off
Video fiber 1 input not present, but not selected
No
Information
Fiber 2 video input signal not detected
Off
Off
Video fiber 2 input not present, but not selected
No
