Configuration Summary Table
provides a complete summary of the module functions and a com-
parison of the functionality available with each control type along with the
ranges and default values for each parameter and notes on each control.
Table 11. Summary of Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Newton
Control
Panel
Coax Video Input signal loss reporting
Enable
Enable or Disable
I/O Config/
Coax Video Input
Reporting Enabled checkbox
N/A
Fiber 1 Input submodule video input sig-
nal loss reporting
(SFP-13103G-M1DRX or
SFP-13103G-M1TRX option required for
Fiber RX1)
Enable
Enable or Disable
I/O Config/
Fiber 1 Video Input
Reporting Enabled checkbox
N/A
Fiber 2 Input submodule video input sig-
nal loss reporting
(SFP-13103G-M1DRX option required
for Fiber RX2)
Enable
Enable or Disable
I/O Config/
Fiber 2 Video Input
Reporting Enabled checkbox
N/A
Input Standard Selection
All standards enabled
HD 1080i/59.94,
720p/59.94,
HD 1080i/50,
HD 720p/50,
HD 1080p/23.93,
HD 1080sf/23.98,
480i/59.94, and
576i/50
System Config/
Input Standard Selection
Input Standard checkboxes
N/A
Video Input Select
(select source for input video)
Coax
Coax,
Fiber RX1, or
Fiber RX2
Video Input/
Input Standard Selection
Select Input Video radio button
VinSrcSel
Audio Output 1 Stream Selection
Audio Output 2 Stream Selection
Audio Output 3 Stream Selection
Audio Output 4 Stream Selection
Coax In.G1.S1,
Coax In.G1.S2,
Coax In.G2.S1,
Coax In.G2.S2,
Force Silence,
Coax In.G1.S1,
Coax In.G1.S2,
Coax In.G2.S1,
Coax In.G2.S2,
Coax In.G3.S1,
Coax In.G3.S2,
Coax In.G4.S1,
Coax In.G4.S2.
Audio De-Embedder/
Audio Output 1-4
Stream Selection pulldown
DmbAES1Sel
DmbAES2Sel
DmbAES3Sel
DmbAES4Sel
Audio Output 1 Resolution
Audio Output 2 Resolution
Audio Output 3 Resolution
Audio Output 4 Resolution
Pass
Pass,
20 bit, or
24 bit
Audio De-Embedder/
Audio Output 1-4
Resolution pulldown
Out1ResSel
Out2ResSel
Out3ResSel
Out4ResSel
