50 8925DMB-B and -U — Instruction Manual
Specifications
Table 8 provides the video and audio latency and video/audio offset
values between the audio and video for software versions 1.0.0 and 2.0.0.
Timing jitter (HPF 10 Hz) HD/SD: 1UI/0.2UI
Alignment jitter HD/SD: 0.2UI (HPF 100kHz) / 0.2UI (HPF 1kHz)
Output return loss >15 dB (5 MHz - 1.485 MHz)
Output impedance 75 ohms
Digital Audio Outputs
Balanced Outputs Unbalanced Outputs
Digital audio output signal AES3-1997, Tech 3250-E AES3-id-2001
Number of outputs 4 (J1, J2, J3, J4) 4 (J1, J2, J3, J4)
Output names AES 1, 2, 3, 4 AES 1, 2, 3, 4
Connector type Three pin terminal block BNC
Output rise / Fall time 5ns to 30ns @ 110 Ohms 10 to 20ns @ 75 Ohms
Differential voltage range 3.2 V p-p +/- 0.2 @ 110 Ohms 0.95 ± 0.05V p-p @ 75 Ohms
Output return loss > 15 dB (100kHz - 128 FS) > 15 dB (100 kHz - 128 FS)
Output impedance 110 Ohms +/- 20 % 75 Ohms ± 20 %
Sampling rates supported 48 kHz 48 kHz
Audio data format PCM or non-PCM (SMPTE 337M-2000)
Table 8. Video/Audio Latency and Video/Audio Offset
Input Format
Video Latency
Versions 1.0.0 and 2.0.0
Maximum Audio Latency
Versions 1.0.0 and 2.0.0
Video/Audio Offset
Versions 1.0.0 and 2.0.0
SD (all) 38 T (1.4 μs) 36 AS (0.75 ms) 0.75 ms
HD (all) 49 T (330 ns) 18 AS (0.38 ms) 0.38 ms
Table 7. Digital Video Specifications
