8925DMB-B and -U — Instruction Manual 49
Specifications
Table 6. Environmental and Miscellaneous Specifications
Environmental / Miscellaneous
Safety ANSI/UL60950-1 Safety of Information Technology Equipment,
including Electrical Business Equipment (2003).
CAN/CSA C22.2, No. 60950-01 Safety of Information Technology Equipment,
including Electrical Business Equipment.
cULus certification File number: E300838
IEC 60950-1 Safety of Information Technology Equipment,
including Electrical Business Equipment (2003).
EN60950-1 Safety of Information Technology Equipment,
including Electrical Business Equipment (2001).
73/23/EEC Low voltage directive (19/02/73) amended by 93/68/EEC (22/07/93)
89/336/EEC directive (05/05/89) amended by 93/68/EEC (22/07/93)
EMC FCC Class A CISPR Pub. 22 (1985)
EN55103-1 (1997)
EN55103-2 (1997)
EU marking 93/68/EEC (22/07/93)
Climatic
specifications ETS 300 019-1-3 class 3.1
(Feb. 1992) Operating temperature (for 8900FFN model): + 0°C to + 45°C
Operating humidity: 10% to 95% non-condensing
ETS 300 019-1-1 class 1.1
(Feb. 1992)
Storage temperature: - 10 °C to 70°C
MTBF at 40ºC
8925DMB front module 731,000 hours
8900UVF-R rear module 25,575,000 hours
8900UVF-R rear module 26,385,000 hours
Table 7. Digital Video Specifications
Digital Video Input
Serial digital video input signal SMPTE 292M (HD) and SMPTE 259M-C (SD) compliant
Number of inputs 1 HD/SD (J9)
Connector type BNC
Jitter tolerance RP184-1996 compliant
Input return loss >15 dB (5 MHz - 1.485 MHz)
Input impedance 75 ohms
Maximum cable length equalization HD: 140m Belden 1694A SD: 350m Belden 1694A
Digital Video Outputs
Serial digital video output signal SMPTE 292M (HD) and SMPTE 259M-C (SD) compliant
Active loop through output 1 reclocking output (J7)
Number of outputs, names 3 HD/SD outputs (J5, J6, J8)
Connector type BNC
Signal level 800 mV ± 10%
Equalization If coax input selected
Reclocking Yes
Reclocked SDI output electrical length 4T (SD); 5T (HD); T = 1/2 pixel rate
