GUIDE TO INSTALLATION AND OPERATION
Kaleido-Solo | 59
Control - Standard
Linear (True Peak)
EBU Digital (True Peak)
(IEC60268-18 true peak)
EBU Digital (Peak Type I)
(IEC60268-18 type I)
VU Meter (0dBu)
(IEC60268-17) Analog VU (0VU = 0dBu)
Vu Meter (+4dBu)
(IEC60268-17) Analog VU (0VU = +4dBu)
UK PPM
(IEC60268-10 type IIa) Analog peak
EBU PPM
(IEC60268-10 type IIb) Analog peak
Nordic PPM
(IEC60268-10 type I) Analog peak
DIN PPM
(IEC60268-10 type I) Analog peak
Display - ALM 5.1 (Left and Right side)
Checked
Show the 5.1 audio level meters.
Unchecked
Hide the 5.1 audio level meters, leaving space to show up to 3 stereo audio level meters.
Display - ALM1, ALM2, etc.
For each of the eight available ALMs:
Checked
Show the stereo meter.
Unchecked
Hide the stereo meter.
