6 XML Gateway
The XML Gateway is a protocol used to control OSD objects of the Kaleido-Solo.
Below is a table containing all accessible objects from the XML Gateway protocol. The port number used for the
connection is
„13000‟.
You must send an <openID/> command to open a session.
Object
ID/Address
Gateway message
Behavior
Picture frame & UMD
0
<setKStatusMessage>
status="new status"
</setKStatusMessage>
NORMAL or OK
Gray frame, white UMD text
WARNING or MINOR
Yellow frame and UMD text
CRITICAL or ERROR
Red frame and UMD text
UMD
0
<setKDynamicText>
Text
=”new text”
</setKDynamicText>
UMD text will change to the requested
string. (UMD text source must be
configured to use Ethernet)
Program Preset
(red-right)
1
<setKStatusMessage>
status="new status"
</setKStatusMessage>
NORMAL or OK
Unlit tally
WARNING or MINOR
Red lit tally
CRITICAL or ERROR
Red lit tally
Tally Preset
(green-left)
2
<setKStatusMessage>
status="new status"
</setKStatusMessage>
NORMAL or OK
Unlit tally
WARNING or MINOR
Green lit tally
CRITICAL or ERROR
Green lit tally
