HEIDENHAIN MANUALplus 620 181
4.4 T
u
rn
ing cy
cles
Type of machining for technology database access: Finishing
Cycle run
1 Move paraxially from the starting point to the ICP contour starting
point
2 Finish defined contour area
3 Move to the tool change point according to the G14 setting
MFS M at beginning: M function that is executed at the
beginning of the machining step
MFE M at end: M function that is executed at the end of the
machining step
WP Displays which workpiece spindle is used to process the
cycle (machine-dependent)
 Main drive
 Opposing spindle for rear-face machining
