Yaskawa GPD 515/G5 to F7 - Manual (Page 35)

Product Transition Guide
Appendix 2- Parameter Differences
____________________________
PL.F7.02.TransitionGuide 6/5/06
Page 35 of 40
Yaskawa Electric America, Inc
GPD515/G5 Parameters F7 Parameters
Parameter
No.
Name
(DigitalOperator
Display)
Setting or Selection
Parameter
No.
Name
(Digital Operator Display)
Remarks on
Setting or Selection
— — — H5-07 RTS Control Selection
New parameter
0: Disabled RTS is always on
1: Enabled RTS turns on
only when sending
— — — H6-01 Pulse Train Input
Function Selection
New parameter
0: Frequency reference
1: PID feedback value
2: PID setpoint value
— — — H6-02 Pulse Train Input
Scaling New parameter
— — — H6-03 Pulse Train Input Gain New parameter
— — — H6-04 Pulse Train Input Bias New parameter
— — — H6-05
Pulse Train Input Filter
Time New parameter
— — — H6-06
Pulse Train Monitor
Selection New parameter
— — — H6-07
Pulse Train Monitor
Scaling New parameter
L1-01 Motor Protection
Selection
MOL Fault Select 0:Disabled
1:Coast to Stop
See: GPD515/G5 E1-02 L1-01 Motor Overload
Protection Selection Modified function
0: Disabled
1: Fan Cooled <10:1 motor
2:Blower Cooled 10:1 motor
3: Vector Motor 1000:1 motor
— — — L1-03 Motor Overheat Alarm
Operation Selection New parameter
0: Ramp to Stop
1: Coast to Stop
2: Fast-Stop
3: Alarm Only
— — — L1-04 Motor Overheat Fault
Oper ation Selection New parameter
0: Ramp to Stop
1: Coast to Stop
2: Fast-Stop
— — — L1-05 Motor Temperature
Input
Filter Time New parameter
— — — L2-07 Momentary Recovery
Time New parameter
— — — L2-08 Frequency Reduction
Gain at KEB Start New parameter
L3-07 Stall Prevention
Function P Gain — — — Deleted in F7
L3-08 Stall Prevention
Function Integral
Time — — — Deleted in F7
L4-05 Frequency Loss
Detection Selection 0: Stop
1: Run@ 80% PrevRef L4-05 Frequency Reference
Loss
Detection Selection Modified function
0: Normal Operation - Drive
will run at the frequency
reference.
1: Run at L4-06 PrevRef
Drive will run at the
percentage set in L4-06
— — — L4-06 Frequency Reference
Level at Loss
Frequency New parameter
