10 EN
Names of parts
Names of parts
1
2
3
4
5
6
7
5
8
9
0
a
b
d
c
e
g f
h
i
1 Mode dial ........................................P. 20
2 Shutter button .................................P. 21
3
ON/OFF button ..............................P. 16
4 Control dial* (P) ......... P. 31-33, 45, 66
5 Strap eyelet.....................................P. 12
6 Lens attachment mark ....................P. 15
7 Mount (Remove the body cap before
attaching the lens.)
8 Hot shoe cover
9 Stereo microphone .............P. 62, 70, 86
0 Self-timer lamp/AF illuminator
...............................................P. 54/P. 88
a Lens release button ........................P. 15
b Lens lock pin
c Tripod socket
d Battery/card compartment lock .......P. 13
e Battery/card compartment cover.....P. 13
f Connector cover
g Multi-connector ............. P. 100, 116, 119
h HDMI connector (Type D) .............P. 100
i Card slot .........................................P. 14
* In this manual, the P icon represent operations performed using the control dial.
