2
8. Hang the fan on the hook of the mounting plate,
refer to the instruction manual included with your
fan for the wire connections. An additional safety
support is provided to prevent the fan from falling
fan). Place the endof cable through the loop of
ceiling support cable. Pull as much cable through
loop as possible. Feed end of cable into clamp
hole and fi rmly tighten screw. Cut off excess
safety cable. Secure the safety cable to the ceiling
joist with screw and washer. (Fig. D)
9. Secure the ceiling fan canopy to the mounting
plate with the four 3/16" x 3/8" screws and lock
washers provided. (Fig. E) Raise canopy ring up
against canopy and secure it to canopy until snug.
Fig. E
Fig. D
Screws
Canopy ring
Mating holes
Ceiling Adapter Kit
Attach safety cable
to ceiling joist with
screw and washer
Wood screw
