6-11
Sending Faxes from PC > Basic Transmission
Default Settings Dialog Box
By setting the transmission conditions that you use most in this dialog box, you can minimize
the need to change the settings each time.
The Default Settings dialog box can be accessed by the following procedure:
1
Display the screen.
1 Click the [Start] button on the taskbar, click [Control Panel], and then click [View devices
and printers].
2 Right click the name of the machine to be used as the network fax and select [Printing
preferences] from the resulting drop-down menu. Click the [FAX TX Setting] button in the
[Printing Preferences] window.
2
Configure the settings.
(1) Sending Options Tab
Item Description
FAX Delayed Transmit
checkbox Check the checkbox in order to activate the time fields to the right of
the checkbox whenever you want to set the time that your
documents will be transmitted. The desired time setting can be
entered directly with the keyboard or by clicking on the S and T
arrows.
IMPORTANT
If the time that is shown in the message display of this fax
machine does not match the current time, communications that
use the timer may not be accomplished as expected. If the
displayed time is not current, be sure to adjust it to match the
correct time.
NOTE
If you designate a time that is earlier in the day than the time that is
actually displayed in the fax machine itself, the transmission
operation will be carried out the following day at that time. Be sure to
confirm the time setting in the fax machine itself before making this
setting.
Value : 00:00-23:59
Transmit and Print
checkbox Check the checkbox when you want to print out the documents at
the fax machine same time as you send them by fax.
Display confirm dialog
checkbox You can check the checkbox to display the destination confirmation
screen and check the destinations before transmission.
