Amprobe BDM40-UA Bench-Digital-Multimeter User Manual
Page 23
22
Ohms Calibration
On the UUT select ‘
Ω ‘, 200Ω range, and connect the V-Ω terminal to the calibrator HI ohms output and COM to
the calibrator LO ohms output. For each step in Table 9, select the listed range, program the calibrator for the
corresponding UUT input, and make the specified adjustment or check.
Table 9. Ohms Calibration
Step Range
Input
Adjust
Display
Limits
1
2
20 M
Ω
20 k
Ω
10 M
Ω
10 k
Ω
VR402
VR401
9.995 to 10.005
9.998 to 10.002
DC Current Calibration
On the UUT select DC, 20 A range, and connect the 20A terminal to the calibrator HI amps output and COM to the
calibrator LO amps output. For each step in Table 10, select the listed range, program the calibrator for the
corresponding UUT input, and make the specified adjustment or check.
Table 10. DC Current Calibration
Step Range
Input Adjust Display
Limits
1
2
3
20 A
2 A (2000mA)
200 mA
+ 1.9 A
+ 1.9 A
+ 190.00 mA
VR206
VR205
VR204
+ 1.898 to 1.902
+ 1899.8 to 1900.2
+ 189.98 to 190.02
AC Volts Calibration
On the UUT select AC only, 2 V range, and connect the V-
Ω terminal to the calibrator HI volts output and COM to
the calibrator LO volts output. For each step in Table 11, select the listed range, program the calibrator for the
corresponding UUT input, and make the specified adjustment or check.
Table 11. AC Voltage Calibration
Step Range Input Freq.
Adjust
Display
Limits
1
2V
Short
VR501
Less than .0010
2
3
2V
1.9000V
400Hz
VR502
SVC202/203
1.8995 to 1.9005
ADJ to mechanical center
4(a)
(b)
5(a)
(b)
200V
20V
1000v
20V
100.00V
19.000V
1000.0v
19.000V
1 kHz
10 kHz
1 kHz
10 kHz
SVC201
SVC202
SVC201
SVC203
99.90 to 100.10
18.990 to 19.010
999.5 to 1000.5
18.990 to 19.010
MAINTENANCE AND REPAIR
Changing Input Power Configuration
This meter was shipped with power cords and fuses for 117V (USA) and 230V (European) operation. The initial
configuration is for 230V.
