User’s Manual of EPL-2000
4.2.2 Basic Information
The Basic System Info page provides information for the current device information. Basic System Info page helps an OLT
administrator to identify the firmware / hardware version, System Config and Switch Mode Configure.
Figure 4-22
Basic Information Screen
The window includes the following fields:
Object Description
Card Type:
The OLT device type, EPL-2000 is epon-olt type.
Serial NO.:
The manufacture number.
Hardware Version:
The version of Current Hardware.
Firmware Version:
The version of Current Firmware.
Running Status:
Status of EPL-2000.
Running Time:
The period of time the device has been operational.
Console Port Speed:
The baud rate of Console Port. (Only for Manufacturer)
oam Type:
The default type is ctc-broadcom.
Read Community:
Indicates the community read access string to permit access to SNMP agent.
R/W Community:
Indicates the community write access string to permit access to SNMP agent.
Trap Receiver
1~4 IP Address:
Assign IP address of host to receive trap from the device.
Outbandip:
Manage Port IP address, the default is 192.168.1.10.
OutbandMask:
Manage Port subnet mask, the default is 255.255.255.0
