Epson SureColor P8570DL 44" Wide-Format Dual Roll Printer with High-Capacity 1.6L Ink Pack System User Manual
Page 297
297
Setting
Options
Description
Auto Cleaning
On
Select the option to automatically perform a
print head check and cleaning when the
printer turns on and before printing
Select
Standard
to set a normal automatic
cleaning
Select
Custom
to set the timing and
frequency of automatic cleaning from the
following options:
•
Nozzle Check Schedule
: Sets whether to
perform a nozzle check during printing or
only after printing has finished
•
Nozzle Check Sensitivity
: Adjusts the
number of clogged nozzles that trigger a
cleaning cycle
•
Nozzle Check Result Notice
: Sets
whether the printer reports if there are still
clogged nozzles after automatic cleaning
Off
Disables the print head checking and
automatic cleaning
Printing Language
*
USB
Network
Select the printing language to use for each
connection mode
Auto
: select for most printing situations
HP-GL/2
: select if HP-GL/2 or HP RTL print
data sent from a CAD application does not
automatically switch the printing mode
PS
: select if PS print data does not
automatically switch the printing mode
(available only on models with Adobe
Embedded Print Engine)
Universal Print Settings
*
Various options
See the
Universal Print Settings
table below
HP-GL/2 Unique Settings
Various options
See the
HP-GL/2 Unique Settings
table
below
