323

Setting

Description

Power Cleaning

Perform if the nozzle check pattern still has faint or missing
areas after performing a head cleaning three times in a row

Remove Paper

Removes any scraps of paper remaining inside the printer

Ink Cartridge(s) Replacement

Displays the amount of ink remaining and the model number
for the ink cartridge

Select

How To...

to view the replacement procedure on the

LCD screen.

Replace Maintenance Box

Displays the amount of free space remaining and the model
number of the selected maintenance box

Select

How To...

to view the replacement procedure on the

LCD screen.

Replace Auto Cutter Blade

Select

How To...

to view the replacement procedure on the

LCD screen.

Adjust Cut Position

Adjust the position of the cutter between -3.0 to 3.0 mm

Cleaning the Maintenance Parts

Select

Wiping the Print Head

to manually clean the print

head or

Wiping around the Cap

to manually clean the area

around the caps and press

Start

to move the print head to the

cleaning position.

Keeping Preparation

Perform if you are transporting or storing the printer in 14°F
(–10°C) or lower temperatures. Follow the prompts to eject the
ink. The printer turns off automatically after the procedure.

*The

Power Cleaning

and

Keeping Preparation

settings can be locked by an administrator. If you

cannot access or change these settings, contact your administrator for assistance.

Parent topic:

Using the Control Panel Menus
